The suspended spiral pump head inspired by the image of a vortex provides outstanding cooling performance and various lighting effects from different angles.
High Performance Cooling
Performance data tested with Vortex 360 on AMD Ryzen 5600x
The EPDM high-density tubing is very durable, making less loss of liquid.
Massive 13 fins dissipate heat rapidly.
The Vortex 360 ARGB adopted the Antec Fusion PWM ARGB Fan with a unique multilateral-shaped lighting frame with 16 LEDs projecting the most harmonious lighting effects and providing more powerful cooling for the CPU.
The included ARGB controller works with the motherboard, customizing each individual LED in colour and effect.
AMD: AM3/AM4/AM5/TR4
Intel: LGA 115X/1200/1700/20XX
| Is Discontinued | No |
|---|---|
| SKU | ANTEC-AIO-VORTEX-360-ARGB-W |
| Brand | Antec |
| UPC/EAN | 0761345740494 |
| Radiator Dimensions | 397 x 120 x 27 mm |
| Radiator Material |
Aluminium |
| Pump Dimensions |
￠67 x 48.5 mm |
| Rating Voltage |
DC 12 V |
| Minimum Start-up Voltage |
≥ 5.0 V |
| Fan Speed | 2800±10% RPM |
| Rated Current |
0.25±20% A |
| Consumed Power |
3.0 W |
| Flow Rate |
≥ 1300 mL / min |
| Water Pressure |
1.4M |
| Operation Temperature |
-10°C ~ +60°C |
| Noise Level | ≤ 28 dB(A) |
| Lifespan | 40,000 hours |
| Connector | PUMP: 3-pin | LED: 3-pin |
| Model Name |
Fusion 120 ARGB fan |
| Fan Type |
PWM fan |
| Fan Dimensions |
120 x 120 x 25 mm |
| Bearing Type |
Hydraulic Bearing |
| LED Type |
Addressable RGB |
| Fan Speed |
600±200 ~ 2000±10% RPM |
| Airflow |
57.93 CFM (max.) |
| Air Pressure | 2.11 mmH₂O (max.) |
| Fan Noise Level | 31.24 dB(A) |
| Lifespan | 40,000 hours |
| Connector |
FAN: 4-pin PWM | LED: 3-pin |
| Rated Voltage |
FAN: DC 12 V | LED: DC 5 V |
| Operational Voltage |
FAN: DC 6.0-13.8 V | LED: DC 4.5-5.5 V |
| Rated Current |
≤ 0.21 A | LED : ≤ 0.58 A |
| Socket Compatibility |
Intel : LGA 115X / 1200 / 1700 / 20XX AMD: AM3 / AM4 / AM5 / TR4 |
| Warranty |
3 Years |
